A 1.2m LED bargraph display unit from Metrix Electronics UK’s Migra/Migan Microsyst range is in use at a steel mill.

The unit provides distance readable indication of the level of molten steel in a vessel for at-a-glance monitoring by workers in this safety-critical environment.

An integral heater was included inside the IP65 aluminium case to cope with temperature swings in the mill building.

Metrix’s 1.2m tall bargraph display improves steel-making safety.

The customer’s brief:
“…a large 500-1000mm tall bar graph with numeric display
for use in a steel mill on the cast floor. It will be exposed to
very dirty environment with seasonal temperature swings
from -7 to +35ºC. “

The customer’s verdict:
“Thank you very much. I will tell you that we are trying to
promote your bargraph as an option for our measurement
system. I hope we can sell a lot of them.”



Combination migra graphic and migan numeric displays


Steel Making Plant Contractor


Display of level of molten steel

  • 1m analogue LED bargraph with programmable colours
  • 100mm LED digits
  • AD Converter input
  • RS232 Configuration
  • Integrated heater
  • IP65 protection
